Grey Water Effluent Treatment Plant 10 KLD

Send Inquiry

Request To Call Back

Grey Water Effluent Treatment Plant 10 KLD

Price 450000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Grey Water Effluent Treatment Plant 10 KLD Specification

Membrane Size
2 Micron

Power
12 kW

Material
Stainless Steel

Installation Type
Containerized Plug & Play

Ph Level
6.5 - 8.5

Application
Commercial

Water Source
Grey Water (Domestic, Industrial)

Automation Grade
Fully Automatic

Membrane Quantity
5 units

Capacity
10000 Liters/Day

Flow Rate
10 m3/day

Treatment Technique
Mixed Bed Bio Reactor + Activated Carbon + Filtration

Product Type
Effluent Treatment Plant

Technology
Advanced Membrane Bioreactor (MBR)

Power Source
Electricity

Operation Type
Semi Automatic

Pressure
3.5 kg/cm2

Dimension (L*W*H)
3500 x 1500 x 2100 mm

Weight
2.6 Ton

Color
Grey

Capacity Intel Flow Rate
Up to 10000 LPD

Ambient Temperature Range
5C to 45C

Control Panel
PLC Based

Chemical Dosing System
Integrated

Noise Level
Low (<60 dB)

Service Required
Quarterly

Disinfection
UV/Chlorination (Optional)

Inlet TSS Removal
Up to 90%

Outlet Water Quality
Suitable for gardening, irrigation, flushing

Skid Mount
Yes

Sludge Handling System
Provided

Inlet/Outlet Diameter
100 mm / 75 mm

Grey Water Effluent Treatment Plant 10 KLD Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
100 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Grey Water Effluent Treatment Plant 10 KLD

Reserve your position at the forefront of water reuse with our venerable Grey Water Effluent Treatment Plant. Capitalise on cutting-edge Mixed Bed Bio Reactor and MBR technologies designed to deliver optimum results, removing up to 90% of inlet TSS. Highlighted by its fully automatic, PLC-based control panel and integrated chemical dosing, this stainless steel champion ensures consistently high water quality-suitable for gardening, irrigation, and flushing. Experience low-noise operations, safe disinfection options, robust sludge handling, and plug & play containerised installation. Ideal for commercial usage across India, this advanced system champions sustainability and efficiency.

Competitive Advantages & Special Features

Our Grey Water Effluent Treatment Plant stands out for its advanced membrane bioreactor (MBR) technology, delivering optimum attenuation of suspended solids and superior water quality. Special features include a fully automatic PLC-controlled operation, integrated chemical dosing, robust stainless steel build, and a versatile plug & play containerized design, simplifying installation. This champion solution caters to commercial applications such as gardening, irrigation, and toilet flushing, empowering businesses to confidently address sustainability and regulatory needs.

Export Market, Packaging & Shipping Details

All shipped goods are expertly packed to ensure integrity during transportation. Our Grey Water Effluent Treatment Plant is securely packaged in galvanized containers, ideal for bulk export markets. FOB Port is typically located in India, with flexible arrangements upon request. Sample units are available for testing or demonstration purposes, providing prospective buyers a clear insight into product quality before committing to bulk orders.

FAQ's of Grey Water Effluent Treatment Plant:

Q: How does the Grey Water Effluent Treatment Plant process grey water?

A: The plant uses a combination of a mixed bed bio reactor, activated carbon, and advanced membrane bioreactor (MBR) technology to efficiently remove suspended solids and contaminants from grey water, ensuring the treated water is suitable for gardening, irrigation, and flushing.

Q: What are the main benefits of using this treatment plant?

A: Key benefits include up to 90% TSS removal, low noise operation, energy-efficient semi-automatic control, safe disinfection options, and robust, stainless steel construction. Additionally, the system promotes water conservation, reduces environmental impact, and helps meet regulatory standards.

Q: Where can the treated water be used after treatment?

A: The treated water produced is ideal for non-potable applications such as gardening, irrigation, and flushing toilets, making it suitable for commercial complexes, hotels, educational institutions, and various industrial settings.

Q: What type of maintenance service is required for the plant?

A: Quarterly maintenance service is recommended to ensure optimal performance. This includes checking membranes, cleaning the system, verifying chemical dosing, and routine inspection of all key components by trained professionals.

Q: How is the plant installed and what are its space requirements?

A: The plant comes in a containerized, plug & play design, simplifying installation. Its compact dimensions (3500 x 1500 x 2100 mm) make it suitable for most commercial sites. The skid-mount feature further facilitates easy placement and integration.

Q: What makes this treatment plant suitable for export markets?

A: Its modular, containerised construction ensures safe and easy shipping. The plant complies with international quality standards, and secure packaging safeguards against shipping damage, making it ideal for export to various markets.
